The all-new Creta rewrites the book on compact crossovers. The style is sensuous and sporty, reflecting Creta’s impressive dynamic capabilities and fun-loving driving personality.
*Spesifikasi dan kelengkapan berbeda di setiap negara dan sewaktu-waktu dapat berubah tanpa pemberitahuan terlebih dahulu
| All New Hyundai CRETA Technical Specification | ||||
| Dimension | 6MT | IVT | ||
| Exterior | ||||
| Overall length | mm | 4,315 | ||
| Overall width | mm | 1,790 | ||
| Overall height (roof rack) | mm | 1,630 | ||
| Wheelbase | mm | 2,610 | ||
| Wheel tread | front / rear, mm | 1.572 / 1.576 | ||
| Overhang | front / rear, mm | 855 / 850 | ||
| Ground clearance | mm | 200 | ||
| Interior | ||||
| Head room (with sunroof) | 1st / 2nd row, mm | 1.017 (980) / 985 | ||
| Leg room | 1st / 2nd row, mm | 1.051 / 973 | ||
| Shoulder room | 1st / 2nd row, mm | 1.404 / 1.380 | ||
| Hip room | 1st / 2nd row, mm | 1.312 / 1.310 | ||
| Cargo area - VDA | minimum / maximum, L | 416 / 1.384 | ||
| Engine | ||||
| Configuration | Transverse front mounted driving front wheels | |||
| Cylinder capacity | cc | 1,497 | ||
| Cylinder layout | In-line | |||
| Number of cylinders | 4 | |||
| Bore x stroke | mm | 75,6 x 83,4 | ||
| Compression ratio | 10,5:1 | |||
| Maximum power | PS/rpm | 115/6.300 | ||
| kW/rpm | 84,4/6.300 | |||
| Maximum torque | kgm/rpm | 14.7/4.500 | ||
| Nm/rpm | 143,8/4.500 | |||
| Fuel system | MPI (Multi Point Injection) | |||
| Fuel type | Gasoline | |||
| Fuel tank capacity | L | 40 | ||
| Emission standard | EURO 4 | |||
| Transmission | ||||
| Type | 6-speed manual | CVT | ||
| Gear ratio (:1) | 1st | 3.833 | 2,680 ~ 0,385 | |
| 2nd | 2.143 | |||
| 3rd | 1.370 | |||
| 4th | 1.036 | |||
| 5th | 0.839 | |||
| 6th | 0.727 | |||
| 7th | - | |||
| Reverse | 3.700 | 2,822 ~ 1,822 | ||
| Final | 4.563 | 6.483 | ||
| Clutch Type | Dry single plate | - | ||
| Steering | ||||
| Type | Column - Motor Driven Power Steering (C-MDPS) | |||
| Overall steering gear ratio | 16.4 | |||
| Number of steering wheel turns lock-to-lock | 2.98 | |||
| Minimum turning radius | m | 5.4 | ||
| Suspension | ||||
| Front | MacPherson Strut | |||
| Rear | Coupled torsion beam axle (CTBA) | |||
| Brakes | ||||
| General | Dual-diagonal, split-circuit, power-assisted braking system with EBD | |||
| ABS | 4-wheel electronic, 4-sensor, 4-channel electronic brake distribution, brake torque distribution system (EBD) |
|||
| Front brake type | 15in (Φ280) ventilated disc, floating-caliper brakes | |||
| Rear brake type | 14in (Φ262) solid disc, floating-caliper brakes | |||
| Vacuum booster | Diameter | 10,5in | ||
| Boosting ratio | 9:1 | |||
| Master cylinder | Type | Fixed seal | ||
| Diameter, mm | 22.22 | |||
| Parking brake | MT / AT | EPB | ||
| Wheels & Tires | ||||
| Wheel dimensions | 6,5 x 17in alloy wheel | |||
| Tire size | 215/60R17 | |||
| Spare wheel type | 6,5 x 17 (Steel) w/ 215/60R17 | |||
| Weight | ||||
| Curb weight | Lightest / heaviest, kg | 1.165 / 1.175 | 1.200 / 1.245 | |
| Gross Vehicle Weight (GVW) | kg | 1,590 | 1,660 | |
| Permissible Axle Weight (PAW) | Front / rear, kg | 880 / 820 | 880 / 820 | |
